3M Polyester Protective Tape 335, Pink, 12 in x 144 yd, 1.6 mil, 1 Roll/Case

Details

• Extensible, abrasion resistant backing is ideal for forming operations
• Hand-moldable feature allows for easy application (no special tools or damming required)
• Low tack rubber adhesive adheres to a wide variety of surfaces with minimal adhesion build-up and clean removal when finished, even on large surfaces
• Performs at temperatures up to 150°F/66°C for extended periods of time
• Pink color provides easy visibility for either application or removal, providing quick identification of protected versus unprotected areas
• Provides excellent abrasion, tear, scratch, puncture and moisture resistance to help protect surfaces

Product Name: 3M™ Polyester Protective Tape 335, Pink, 12 in x 144 yd, 1.6 mil, 1 Roll/Case

Product Description: 3M™ Polyester Protective Tape 335 is a thin, pink colored, polyester film tape with a low tack rubber adhesive. It is designed to protect polished metal and plastic surfaces during production, packing, shipping and installation with minimal adhesion build-up and clean removal.

Thin, Visible Surface Protection
3M™ Polyester Protective Tape 335 is a 1.5 mil, polyester film tape designed to protect finished surfaces from light abrasion, nicks and scratches. The pink colored tape provides a clear and definitive identification of the protective area, while also providing visibility for application or removal. This tape offers excellent heat, abrasion, tear, scratch, impact and puncture resistance. It can withstand extended exposure to temperatures up to 150°F/66°C, and short term (30 minutes or less) exposure up to 250°F/121°C.

Recommended Applications

• Protection from fumes and splash during plating processes on the upper portion of printed wiring boards
• Protection of polished stainless steel and aluminum in fabrication, shipping and storage
• Protection of nameplates and instrument panels during shipping and installation
• Protection of finished, non-metallic surfaces
• Protection of non-image side of inner layers of multi-layer printed wiring boards

Low-Tack Adhesion with Minimal Build-Up
3M™ Polyester Protective Tape 335 features a low tack, clear, rubber adhesive that adheres to a wide variety of surfaces, including polished metal and plastic surfaces. This adhesive features minimum adhesion build-up and removes easily and cleanly, even when used on large surfaces. It won't mar or leave sticky residue behind, making it ideal for finished surfaces. Extended exposure to direct sunlight, high stacking pressures and extended application to copper bearing surfaces may increase adhesion levels.

Technical Specifications:
- Country of Origin: Mexico
- ECCN Number: EAR99
Logistics and Handling:
- 3M Stock: 7010045100
- Legacy Stock Number: 70006039039
- 3M Catalog Number: 335
- Sales UOM: Roll
- Sales UPC: 00021200055683 (021200055683)
- Smallest Saleable Unit UPC: 00021200055683 (021200055683)
- Shipper UPC: 00021200055683 (021200055683)
- Typical Lead Time: 19 Days
- Shelf Life: 365 Days
- United States Department Of Transportation Ground (US DOT, 49 CFR): NOT REGULATED
- International Air Transport Association: NOT REGULATED
Additional Information:

Thin, Visible Surface Protection
3M™ Polyester Protective Tape 335 is a 1.5 mil, polyester film tape designed to protect finished surfaces from light abrasion, nicks and scratches. The pink colored tape provides a clear and definitive identification of the protective area, while also providing visibility for application or removal. This tape offers excellent heat, abrasion, tear, scratch, impact and puncture resistance. It can withstand extended exposure to temperatures up to 150°F/66°C, and short term (30 minutes or less) exposure up to 250°F/121°C.

Recommended Applications

• Protection from fumes and splash during plating processes on the upper portion of printed wiring boards
• Protection of polished stainless steel and aluminum in fabrication, shipping and storage
• Protection of nameplates and instrument panels during shipping and installation
• Protection of finished, non-metallic surfaces
• Protection of non-image side of inner layers of multi-layer printed wiring boards

Low-Tack Adhesion with Minimal Build-Up
3M™ Polyester Protective Tape 335 features a low tack, clear, rubber adhesive that adheres to a wide variety of surfaces, including polished metal and plastic surfaces. This adhesive features minimum adhesion build-up and removes easily and cleanly, even when used on large surfaces. It won't mar or leave sticky residue behind, making it ideal for finished surfaces. Extended exposure to direct sunlight, high stacking pressures and extended application to copper bearing surfaces may increase adhesion levels.

Important Links:

Tech Data Sheet
- EU REACH: This product, including any article that the product is composed of, does contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59.1 of Regulation No 1907/2006 of the European Parliament and the Council concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH), per listing of candidates and Annex XIV. This declaration reflects the substances on the candidate SVHC list, effective January 2022. Refer to SDS or comment for identification of SVHC(s).; This product, including any article that the product is composed of, does contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59.1 of Regulation No 1907/2006 of the European Parliament and the Council concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH), per listing of candidates and Annex XIV. This declaration reflects the substances on the candidate SVHC list, effective January 2023. Refer to SDS or comment for identification of SVHC(s).; This product, including any article that the product is composed of, does contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59.1 of Regulation No 1907/2006 of the European Parliament and the Council concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH), per listing of candidates and Annex XIV. This declaration reflects the substances on the candidate SVHC list, effective January 2024. Refer to SDS or comment for identification of SVHC(s).; This product, including any article that the product is composed of, does contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59.1 of Regulation No 1907/2006 of the European Parliament and the Council concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH), per listing of candidates and Annex XIV. This declaration reflects the substances on the candidate SVHC list, effective June 2022. Refer to SDS or comment for identification of SVHC(s).; This product, including any article that the product is composed of, does contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59.1 of Regulation No 1907/2006 of the European Parliament and the Council concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH), per listing of candidates and Annex XIV. This declaration reflects the substances on the candidate SVHC list, effective June 2023. Refer to SDS or comment for identification of SVHC(s).; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2020.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2021.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective July 2019.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective July 2021.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective June 2020.
- EU RoHS: This product does not exceed the maximum concentration values (MCVs) for phthalates set under EU Directive 2011/65/EU (RoHS recast/RoHS 2), as amended by EU 2015/863, which applies to finished EEE after July 22, 2019 for Category 1-7, 10-11 products and after July 22, 2021 for Category 8 and 9 products. This means that each of the homogeneous materials within this product does not exceed the MCV of 0.1% (by weight) for each of the following phthalates: DEHP, BBP, DBP, and DIBP.
