3M Double Coated Double Linered Tape 7953MPD, Clear, 6 in x 540 yd, 1 Roll/Case
Details
- Clear polyester carrier brightens overlays and key pads, eliminating need for floodcoat
- Double linered, 3.5 mil thick double linered, double coated tape aids in separation of switch circuitry until actuation
- Easily die-cutable, featuring clean application
- High shear strength withstands repeated stresses of switch actuation and resists slippage and edge lifting
- Moisture stable liner for easy, layflat processing
- Outstanding adhesion to metal and high surface energy (HSE) plastics
- Provides short term repositionability for placement accuracy
Product Name: 3M™ Double Coated Double Linered Tape 7953MPD, Clear, 6 in x 540 yd, 1 Roll/Case
Product Description: 3M™ Double Linered Double Coated Tape 7953 is a membrane switch product designed with a polycoated kraft paper liner and acrylic adhesive on one side of a clear polyester film carrier. This membrane switch product is engineered with 3M™ 200MP High Performance Acrylic Adhesive, an adhesive with exceptional adhesion and resilience.
Strong Switch Solution that Brightens Overlays
3M™ Double Linered Double Coated Tape 7953 is a membrane switch product with a tan #58 polycoated kraft paper liner and 3M™ 200MP High Performance Acrylic Adhesive on one side of a clear polyester film carrier. This acrylic adhesive provides a smooth layer for consistent actuation and excellent seal-ability of switches. We formulated this adhesive to provide shear strength that resists slippage and edge lifting. We designed this product with a clear polyester carrier that brightens overlay and key pads, eliminating the need for floodcoat. This single coated switch spacer is easy to cleanly die-cut and process.
Recommended Applications
- Lead protection
- Dome retainer sheets
- Printing conductive circuitry
- Building custom spacers
The Strength of Adhesive 200MP
3M™ High Performance Acrylic Adhesive 200MP is an industry standard for graphic attachment and general industrial joining applications. It features outstanding adhesion to metal and high surface energy plastics, making it a popular choice across many industries. This adhesive provides some initial repositionability for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles, providing confidence that the switch will perform through difficult environmental conditions and millions of actuations.
Simple Application for Bright and Consistent Results
For consistent actuation and outstanding adhesion, discover the advantages of using our innovatively engineered 3M™ Double Linered Double Coated Tape 7953. Brighten overlays and key pads and enjoy the clean and simple application with this single coated switch spacer. We designed this product to provide you with the assurance that switches will perform, even in difficult environmental conditions for millions of switch actuations.
Technical Specifications:
- Country of Origin: USA
- ECCN Number: EAR99
Logistics and Handling:
- 3M Stock: 7010334740
- Legacy Stock Number: 70006658895
- 3M Catalog Number: 7953MPD
- Sales UOM: Roll
- Sales UPC: 00051111078563 (051111078563)
- Smallest Saleable Unit UPC: 00051111078563 (051111078563)
- Shipper UPC: 00051111078563 (051111078563)
- Typical Lead Time: 25 Days
- Shelf Life: 547 Days
- United States Department Of Transportation Ground (US DOT, 49 CFR): NOT REGULATED
- International Air Transport Association: NOT REGULATED
Additional Information:
Strong Switch Solution that Brightens Overlays
3M™ Double Linered Double Coated Tape 7953 is a membrane switch product with a tan #58 polycoated kraft paper liner and 3M™ 200MP High Performance Acrylic Adhesive on one side of a clear polyester film carrier. This acrylic adhesive provides a smooth layer for consistent actuation and excellent seal-ability of switches. We formulated this adhesive to provide shear strength that resists slippage and edge lifting. We designed this product with a clear polyester carrier that brightens overlay and key pads, eliminating the need for floodcoat. This single coated switch spacer is easy to cleanly die-cut and process.
Recommended Applications
- Lead protection
- Dome retainer sheets
- Printing conductive circuitry
- Building custom spacers
The Strength of Adhesive 200MP
3M™ High Performance Acrylic Adhesive 200MP is an industry standard for graphic attachment and general industrial joining applications. It features outstanding adhesion to metal and high surface energy plastics, making it a popular choice across many industries. This adhesive provides some initial repositionability for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles, providing confidence that the switch will perform through difficult environmental conditions and millions of actuations.
Simple Application for Bright and Consistent Results
For consistent actuation and outstanding adhesion, discover the advantages of using our innovatively engineered 3M™ Double Linered Double Coated Tape 7953. Brighten overlays and key pads and enjoy the clean and simple application with this single coated switch spacer. We designed this product to provide you with the assurance that switches will perform, even in difficult environmental conditions for millions of switch actuations.
Important Links:
Tech Data Sheet
- EU REACH: This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2020.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2021.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2022.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2023.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2024.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective July 2019.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective July 2021.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective June 2020.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective June 2022.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective June 2023.
- EU RoHS: This product does not exceed the maximum concentration values (MCVs) for phthalates set under EU Directive 2011/65/EU (RoHS recast/RoHS 2), as amended by EU 2015/863, which applies to finished EEE after July 22, 2019 for Category 1-7, 10-11 products and after July 22, 2021 for Category 8 and 9 products. This means that each of the homogeneous materials within this product does not exceed the MCV of 0.1% (by weight) for each of the following phthalates: DEHP, BBP, DBP, and DIBP.
