3M Adhesive Transfer Tape 9498, Clear, 1/2 in x 120 yd, 2 mil, 72 Roll/Case, Lathe Slit

Details

• 60lb Densified Kraft (DK) liner for ease in die-cutting operations
• Bonds well to most substrates, including low surface energy plastics
• Conformable to irregular surfaces
• Moderate temperature resistance up to 250?F (121?C)
• Ultra-high peel strength and excellent shear strength to withstand rigorous splicing applications

Product Name: 3M™ Adhesive Transfer Tape 9498, Clear, 1/2 in x 120 yd, 2 mil, 72 Roll/Case, Lathe Slit

Product Description: 3M™ Adhesive Transfer Tape 9498 offers excellent flying splice and core starting wet grab characteristics. It is typically used in the printing industry and performs well at process speeds exceeding 2,000 feet per minute. This tape can be used in ovens up to 450ºF (232ºC) if dwell times are ten seconds or less and up to 250?F (232?C) for longer periods.

Ideal for Rigorous Splicing Applications
Once bonded, 3M™ Adhesive Transfer Tape 9498 provides excellent peel and shear strength – making it ideal for rigorous splicing applications and bonding plastics to metals. It features 2.0 mil high tack acrylic adhesive mounted on a tan 60 lb. densified kraft paper liner for ease in die cutting applications.

Recommended Applications

• Web splicing
• Core starting
• General purpose bonding

A Well-Balanced Adhesive
The adhesive is a medium-firm pressure sensitive acrylic adhesive system. It features an excellent balance of good initial adhesion (quick stick) and good shear holding power. Shear strength is the measure of pull force directed across the bonded surface, forcing the two surfaces to slide over each other. The formulation gives the adhesive a consistently strong bond across a range of temperatures, from 180°F (82°C) long term to 250°F (121°C) short term and in 450ºF (232ºC) if dwell times are ten seconds or less. By using a robust 60 lb. densified kraft paper release liner, this tape provides reliable performance for industrial applications, such as die-cutting and automated dispensers.

What is Adhesive Transfer Tape?
?3M™ Adhesive Transfer Tapes are rolls of pressure sensitive adhesive pre-applied to a special release liner. For application, the tape is simply pressed, adhesive side down, to a surface and the liner is peeled off. A variety of adhesive properties and liners are available to meet requirements for applications such as nameplate attachment to high and low surface energy plastics, appliance graphic overlays that perform in high temperatures, foam gasketing, web splicing, signs, posters, banners, point-of-purchase displays, and more.

Technical Specifications:
- Country of Origin: USA
- ECCN Number: EAR99
Logistics and Handling:
- 3M Stock: 7010374798
- Legacy Stock Number: 70006432911
- 3M Catalog Number: 9498
- Sales UOM: Roll
- Sales UPC: 00051115259807 (051115259807)
- Smallest Saleable Unit UPC: 50051115259802 (051115259802)
- Shipper UPC: 50051115259802 (051115259802)
- Typical Lead Time: 65 Days
- Shelf Life: 730 Days
- United States Department Of Transportation Ground (US DOT, 49 CFR): NOT REGULATED
- International Air Transport Association: NOT REGULATED
Additional Information:

Ideal for Rigorous Splicing Applications
Once bonded, 3M™ Adhesive Transfer Tape 9498 provides excellent peel and shear strength – making it ideal for rigorous splicing applications and bonding plastics to metals. It features 2.0 mil high tack acrylic adhesive mounted on a tan 60 lb. densified kraft paper liner for ease in die cutting applications.

Recommended Applications

• Web splicing
• Core starting
• General purpose bonding

A Well-Balanced Adhesive
The adhesive is a medium-firm pressure sensitive acrylic adhesive system. It features an excellent balance of good initial adhesion (quick stick) and good shear holding power. Shear strength is the measure of pull force directed across the bonded surface, forcing the two surfaces to slide over each other. The formulation gives the adhesive a consistently strong bond across a range of temperatures, from 180°F (82°C) long term to 250°F (121°C) short term and in 450ºF (232ºC) if dwell times are ten seconds or less. By using a robust 60 lb. densified kraft paper release liner, this tape provides reliable performance for industrial applications, such as die-cutting and automated dispensers.

What is Adhesive Transfer Tape?
?3M™ Adhesive Transfer Tapes are rolls of pressure sensitive adhesive pre-applied to a special release liner. For application, the tape is simply pressed, adhesive side down, to a surface and the liner is peeled off. A variety of adhesive properties and liners are available to meet requirements for applications such as nameplate attachment to high and low surface energy plastics, appliance graphic overlays that perform in high temperatures, foam gasketing, web splicing, signs, posters, banners, point-of-purchase displays, and more.

Important Links:

Tech Data Sheet
Flyer
- EU REACH: This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2022.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2023.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective January 2024.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective July 2021.; This product, including any article that the product is composed of, does not contain at greater than 0.1% by weight a Substance of Very High Concern (SVHC) substance identified according to Article 59 of REACH. This declaration reflects the substances on the candidate SVHC list, effective June 2022.
- EU RoHS: This product does not exceed the maximum concentration values (MCVs) for phthalates set under EU Directive 2011/65/EU (RoHS recast/RoHS 2), as amended by EU 2015/863, which applies to finished EEE after July 22, 2019 for Category 1-7, 10-11 products and after July 22, 2021 for Category 8 and 9 products. This means that each of the homogeneous materials within this product does not exceed the MCV of 0.1% (by weight) for each of the following phthalates: DEHP, BBP, DBP, and DIBP.
